Dimension （Outer Diometer*Inner Dimension * Thickness) | Capacity (pF) | Dielectric Loss- tg δ (%) | Resonant Frequency -Fr(kHz) | Coupling Factor - Kp(%) | Quality Factor-Qm | Application |
Φ10*Φ5*2 | 330 | 0.3 | 145 | ≧0.4 | 800 | For Small Power Transducers: 1) ultrasonic spot welding 2) ultrasonic polishing 3) ultrasonic physiotherapy 4) ultrasonic scaler 5) fine bubbles crushed 6) ultrasonic agitation |
Φ25-Φ10*2 | 900 | 0.3 | 87.0 | ≧0.42 | 800 | |
Φ28*Φ10*3 | 1400 | 0.3 | 59.0 | ≧0.43 | 800 | |
Φ30*Φ10*5 | 1140 | 0.3 | 58.0 | ≧0.44 | 800 | |
Φ32*Φ10*5 | 1255 | 0.3 | 52.7 | ≧0.44 | 800 | |
Φ34*10.5*5 | 1350 | 0.3 | 50.2 | ≧0.45 | 800 | |
Φ34*Φ14*5 | 1390 | 0.3 | 48.5 | ≧0.45 | 800 | |
Φ35*Φ15*5 | 1425 | 0.3 | 46.4 | ≧0.45 | 800 | |
Φ36*Φ15*5 | 1500 | 0.3 | 41.5 | ≧0.45 | 800 | For Medium Power Transducer: 1) Ultrasonic cleaning, 2) ultrasonic descaling 3) ultrasonic extraction 4) phacoemulsification |
Φ38*Φ15*5 | 1735 | 0.3 | 43.8 | ≧0.45 | 800 | |
Φ40*Φ12*5 | 2075 | 0.3 | 44.6 | ≧0.45 | 800 | |
Φ40*Φ15*5 | 1960 | 0.3 | 42.2 | ≧0.45 | 800 | |
Φ45*Φ15*5 | 2565 | 0.3 | 38.7 | ≧0.45 | 800 | |
Φ50*Φ17*5 | 3150 | 0.3 | 34.6 | ≧0.45 | 800 | |
Φ49*Φ23*6 | 2225 | 0.3 | 32.2 | ≧0.43 | 800 | |
Φ50*Φ17*6.5 | 2425 | 0.3 | 34.6 | ≧0.45 | 800 | For High Power Transducer: 1) Ultrasonic Machining, 2) ultrasonic plastic welding, 3) ultrasonic drilling , 4) ultrasonic oil-water emulsions , 5) Spinneret powerful cleaning |
Φ49*Φ23*6 | 2340 | 0.3 | 31.8 | ≧0.43 | 800 | |
Φ50*Φ23*6.5 | 2170 | 0.3 | 31.8 | ≧0.43 | 800 | |
Φ60*Φ30*10 | 1925 | 0.3 | 25.8 | ≧0.43 | 800 | |
Φ70*Φ30*10 | 2850 | 0.3 | 22.7 | ≧0.43 | 800 |
